Log Window: This window is used to display error messages, warnings and information messages.ĭocumentation Window: This window is used to display the documentation related to the symbols and other aspects. Each of these views contains the diagrams.ĭiagram Toolbar: The diagram toolbar displays the symbols of the respective type of diagram.ĭiagram Window: The diagram window is the place where the user draws the diagrams using the symbols from the diagram toolbar. Statusbar: The statusbar at the bottom displays status messages.īrowser Window: The browser window displays the views: Use Case View, Logical View, Component View and Deployment View. Toolbar: The toolbar contains the most frequently used actions like New, Open, Save etc… Overview: Here are some video clips that provide you step-by-step guidance on how to use some of the features in IBM Rational Software Architect. Menubar: The menubar consists of several menus like the file menu, edit menu, view menu etc. Rational Rose is a tool that supports round-trip engineering means a tool that supports conversion of a model to code and from code to a model.Rational Rose is a tool for modeling software systems.
Rational Rose is developed by Rational Corporation which is under IBM.ROSE stands for Rational Object-oriented Software Engineering. Introduction to Rational Rose 17 Views Just as there are many views of a house under construction - the floor plan, the wiring diagram, the elevation plan, there are many views of a software project under development.
